Camera

Image Sensor

1/2.5" Progressive Scan CMOS

Min. Illumination

Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR Color: 0.014 Lux @ (F1.4, AGC ON), 0 Lux with IR

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Support

Day & Night

IR Cut Filter

Digital Noise Reduction

3D DNR

WDR

120dB

3-Axis Adjustment

Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Focal length

2.8 to 12 mm

Aperture

F1.4

FOV

Horizontal field of view: 120° to 36° Vertical field of view: 62° to 20.5° Diagonal field of view: 149° to 42°

Lens Mount

Φ14

IR

IR Range

Up to 50 m

Wavelength

850nm

Compression Standard

Video Compression

Main stream: H.265+/H.265/H.264+/H.264

Sub stream: H.265+/H.265/H.264+/H.264/MJPEG

Third stream: H.265+/H.265/H.264+/H.264

H.264 Type

Main Profile/High Profile

H.265 Type

Main Profile

Video Bit Rate

32 Kbps to 16 Mbps

Audio Compression

G722.1/G711ulaw/G711alaw/G726/MP2L2

Audio Bit Rate

32 to 128kbps

Smart Feature-set

Behavior Analysis

Line crossing detection, intrusion detection, unattended baggage detection, object removal detection

Face Detection

Support

Region of Interest

Support 1 fixed region for each stream


Max. Resolution

3840 × 2160

Main Stream

50Hz: 20 fps (3840 × 2160), 25 fps (2944 × 1656, 2560 × 1440, 1920 × 1080, 1280 × 720)

60Hz: 20 fps (3840 × 2160), 30 fps (2944 × 1656, 2560 × 1440, 1920 × 1080, 1280 × 720)

Sub Stream

50Hz: 25fps (640 × 360, 352 × 288)

60Hz: 30fps (640 × 360, 352 × 240)

Third Stream

50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)

60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240)

Image Enhancement

BLC/3D DNR

Image Setting

Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser

Day/Night Switch

Auto/Schedule/Triggered by Alarm In

Network

Network Storage

Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR

Alarm Trigger

Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error, Alarm output, Alarm input

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

General Function

One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter

API

ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users

3 levels: Administrator, Operator and User

Client

iVMS-4200, iVMS-4500, iVMS-5200

Web Browser

IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+

Interface

Audio

1 input (line in, 3.5 mm), 1 output(3.5 mm), single track

Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

Alarm

1 input, 1 output (max. 12 VDC, 30 mA)

Video Output

1Vp-p composite output (75 Ω/BNC)

On-board storage

Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

SVC

H.264 encoding supports

Reset Button

Support

Audio

Environment Noise Filtering

Support

Audio Sampling Rate

16 kHz

General

Operating Conditions

-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)

Power Supply

12 VDC ± 25%, PoE (802.3at)

Terminal block for DC input

Power Consumption and Current

12 VDC, 1.5A, max. 17W

PoE (802.3at, 42.5V to 57V), 0.1A to 0.5A, max. 19W

Protection Level

IP67, IK10

Material

Metal

Dimensions

Φ144.13×332.73 mm (Φ5.67"× 13.10")

Weight

Camera: 1893 g (4.17 lb.)
