Switching power supply 24V 15.2W 0.63A, DIN rail-mounted, MEAN WELL, HDR-15-24
-
Switching power supply 24V 15.2W 0.63A, DIN rail-mounted, MEAN WELL, HDR-15-24
-
- General
- ModelHDR-15-24
- DC Voltage24V
- Rated Current0.63A
- Current Range0 ~ 0.63A
- Rated Power15.2W
- Voltage Adjustment Range21.6 ~ 29V
- Ripple & Noise (max.)150mVp-p
- Voltage Tolerance±1.0%
- Line Regulation±1.0%
- Load Regulation±1.0%
- Setup, Rise Time2000ms, 80ms/230VAC; 2000ms, 80ms/115VAC at full load
- Hold Up Time (Typ.)30ms/230VAC; 12ms/115VAC at full load
- Voltage Range85 ~ 264VAC; 120 ~ 370VDC (277VAC operational, 390VDC operational)
- Frequency Range47 ~ 63Hz
- Efficiency (Typ.)86%
- AC Current (Typ.)0.5A/115VAC; 0.25A/230VAC
- Inrush Current (Typ.)Cold start 25A/115VAC; 45A/230VAC
- Overload Protection110 ~ 145% rated output power
- Over Voltage ProtectionShut off output voltage, clamping by zener diode
- Withstand VoltageI/P-O/P: 4KVAC
- Isolation ResistanceI/P-O/P: 100M Ohms / 500VDC / 25°C / 70% RH
- Working Temperature-30 ~ +70°C (Refer to "Derating Curve")
- Working Humidity20 ~ 90% RH non-condensing
- Storage Temperature, Humidity-40 ~ +85°C, 10 ~ 95% RH non-condensing
- Temp. Coefficient±0.03%/°C (0 ~ 50°C) RH non-condensing
- Vibration10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Compliance to IEC60068-2-6
- MTBF3724.3K hrs min. (Telcordia SR-332); 1166.1K hrs min. (MIL-HDBK-217F at 25°C)
- Dimensions17.5mm (W) x 90mm (H) x 54.5mm (D)
- Weight74g; 160pcs/12.9Kg/1.09CUFT
- CertificationsIEC62368-1, UL62368-1, UL508, BS EN/EN61558-2-16, BSMI CNS15598-1, EAC TP TC 004
- EMC EmissionBS EN/EN55032 (CISPR32), CNS15936 Class B
- EMC ImmunityBS EN/EN61000-4-2, BS EN/EN61000-4-3, BS EN/EN61000-4-4, BS EN/EN61000-4-5, BS EN/EN61000-4-6, BS EN/EN61000-4-8, BS EN/EN61000-4-11
- Operating AltitudeUp to 2000 meters
- LED IndicatorPower On
- Cooling MethodFree air convection
- MountingType DIN Rail TS35/7.5 or TS35/15
