  •   Router 8 ports Ubiquiti UniFi UDM-Pro-Max-EU

    Router 8 ports Ubiquiti UniFi UDM-Pro-Max-EU

    Inquire about this item
    Price 773.20 €
    Want another price? Suggest yours!
    In stock: 0 pcs

    • General
    • Dimensions442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
    • Weight4.7 kg (10.4 lb)
    • Enclosure materialAluminium CNC, SGCC steel
    • Mount materialSGCC steel
    • ProcessorQuad-core ARM® Cortex®-A57 at 2.0 GHz
    • System memory8 GB DDR4
    • On-board storage32 GB eMMC, Integrated 128 GB SSD
    • Management interfaceEthernet, Bluetooth
    • Networking interfaceLAN: (8) GbE RJ45 ports, (1) 10G SFP+ port, WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port
    • IDS/IPS throughput5 Gbps* (*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.)
    • Power method(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz, (1) USP-RPS DC input, 11.5V DC, 8.7A
    • Power supplyAC/DC, internal, 100W
    • Supported voltage range100—240V AC
    • Max. power consumption100W
    • ESD/EMP protectionAir: ± 15kV, contact: ± 8kV
    • LCM display(1) 1.3" touchscreen
    • ButtonFactory reset
    • Ambient operating temperature-10° to 40° C (14° to 104° F)
    • Ambient operating humidity5 to 95% noncondensing
    • CertificationsCE, FCC, IC
    • PerformanceRedundant WAN with failover and load balancing, WiFi QoS with UniFi APs, Application, domain, and country-based QoS, Application and device type identification, Additional internet failover with LTE Backup, Internet quality and outage reporting
    • Next-generation securityApplication-aware firewall rules, Signature-based IPS/IDS threat detection, Content, country, domain, and ad filtering, VLAN/subnet-based traffic segmentation, Full stateful firewall
    • Advanced networkingLicense-free SD-WAN, WireGuard, L2TP and OpenVPN server, OpenVPN client, OpenVPN and IPsec site-to-site VPN, One-click Teleport and Identity VPN, Policy-based WAN and VPN routing, DHCP relay, Customizable DHCP server, IGMP proxy, IPv6 ISP support
