Battery (AGM) SSB SB (2.3Ah, 12V, F1, VRLA)
-
Battery (AGM) SSB SB (2.3Ah, 12V, F1, VRLA)
-
- General
- Nominal voltage12 V
- Nominal capacity2.3 Ah @ C20 to 1.75 V/cell
- TechnologyAGM (Absorbent Glass Mat), VRLA (Valve Regulated Lead Acid)
- Weight~ 0.85 kg
- Design life time6–9 years (standby use), General Purpose acc. Eurobat
- Internal resistance~ 70 mΩ (fully charged)
- Operating temperature rangeDischarge: -20°C to +60°C, Charge: 0°C to +50°C, Storage: -20°C to +60°C
- Maximum discharge current23 A (5 seconds)
- Maximum charging current0.69 A
- Charging voltageStandby use: 13.7 – 13.9 VDC, Cycle use: 14.6 – 14.8 VDC
- Self dischargeMonthly loss less than 3% at 25°C
- Container materialABS UL94HB (optional UL94-V0)
- Dimensions (L x W x H)177 ±1.5 mm x 35 ±1.5 mm x 62 ±1.5 mm
- Total height68 ±1.5 mm
- Terminal typesFast-on 4.8 mm
- Standards metPN-EN 60896-21:2007, PN-EN 60896-22:2007, PN-EN 61056-1:2013, PN-EN 61056-2:2013, PN-E-83016:1999
- CertificationsISO 9001, ISO 14001
- ApplicationsUPS, Emergency Lighting, Fire Alarm Systems, Security Systems, Energy Utilities, DC Power Supply
