  •   6 ports, 4 PoE ports switch UTEPO UTP6306S-PSB

    6 ports, 4 PoE ports switch UTEPO UTP6306S-PSB

    Inquire about this item
    Price 204.98 €
    Want another price? Suggest yours!
    In stock.

    In stock: 5 pcs
    Manufacturer
    Utepo
    • General
    • ItemsUTP3306TS-PSD
    • Downlink Port4*10/100/1000 Base-T PoE++ RJ-45(Auto-MDI/MDI-X)
    • Uplink Port1*10/100/1000 Base-T RJ-451*1000 Base-X SFP
    • Led Indicators1*PWR, power supply indicators1*Link/Act, SFP port state indicators
    • Dimensions (W*D*H)294mm*180mm*44mm
    • Input Voltage100~240V AC, 50~60Hz
    • Power Consumption≤370W (Full load including PoE)
    • MaterialMetal shell
    • InstallationRack/Desktop/Wall mounted
    • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
    • Forwarding ModesStore and Forward
    • MAC Table2k, support auto learning
    • Switching Capacity12Gbps/non-blocking
    • Packet Forwarding Rate8.928Mpps
    • Port Buffer1MB
    • Jumbo Frame9716 Bytes
    • PoE StandardIEEE 802.3af/at/bt
    • PoE Power Supply TypeEnd-span
    • PoE Pin Assignment3/6/4/5(+), 1/2/7/8(-)
    • PoE Budget90W max for each port, 360W max for whole switch
    • Operating-10℃~50℃, 5%~95% (Non-condensation)
    • Storage-40℃~70℃, 5%~95% (Non-condensation)
    • CertificationsCE, FCC
    • System InformationSystem, Hardware, Time and Firmware
    • IP StatusIP Interfaces, IP Routes and  ARP Table
    • SysLogSystem Log Information
    • Detailed SysLogID and Message
    • MAC TableMAC Address Table: Type, VLAN, MAC Address, CPU and Port Number
    • VLANsMembership and Ports
    • PortsTraffic Overview and Detailed Statistics
    • LACPSystem Status, Port Status and Port Statistics
    • Thermal ProtectionThermal Protection Port Status
    • Green EthernetPort Power Savings Status
    • PoE StatusPower Over Ethernet Status
    • LLDPThermal Protection Port Status
    • Loop ProtectionLoop Protection Status
    • Spanning TreeBridge Status, Port Status and Port Statistics
    • IGMP SnoopingIGMP Snooping Status, Groups Information and IPv4 SFM Information
    • MLD SnoopingMLD Snooping Status, Groups Information and IPv6 SFM Information
    • DHCPServer, Snooping Table, Relay Statistics and Detailed Statistics
    • SecurityPort Security, Access Management Statistics, 802.1X, ACL Status and AAA
    • QoSQoS Statistics and QCL Status
    • IP ConfigIP Configuration, IP Interfaces and IP Routes
    • IP StatusIP Interfaces, IP Routes and ARP Table
    • DHCP ServerDHCP Server Mode Configuration, Excluded IP and Pool
    • NTPNTP Configuration
    • TimezoneSystem Timezone Offset and UTC time
    • SNMPSystem, Trap, Communities, Users, Groups, Views and Access
    • SysLogSystem Log Configuration
    • PortsPort Configuration
    • AggregationStatic and LACP
    • MirroringMirror and Mirror Port Configuration
    • Thermal ProtectionThermal Protection Configuration
    • Green EthernetPort Power Savings and Port Configuration
    • DDMDDM Configuration, DDM Overview and DDM Detailed
    • PoE SettingPower Over Ethernet, PoE Power Supply and PoE Port Configuration
    • PoE StatusPower Over Ethernet Status
    • MAC TableAging Configuration, MAC Table Learning and Static MAC Table Configuration
    • PTPPTP Clock Configuration and PTP Status
    • VLANsGlobal VLAN and Port VLAN Configuration
    • Voice VLANVoice VLAN Configuration and Voice VLAN OUI Table
    • GVRPGVRP Global and Port Configuration
    • Port IsolationPort Group and Port Isolation
    • Loop ProtectionGeneral Settings and Port Configuration
    • Spanning TreeBridge Settings, MSTI Mapping, MSTI Priorities, CIST Ports and MSTI Ports
    • IPMC ProfileProfile Table and Address Entry
    • MEPMaintenance Entity Point
    • ERPSEthernet Rapid Ring Protection Switching
    • IGMP SnoopingBasic Configuration, VLAN Configuration and Port Filtering Profile
    • IPV6 MLD SnoopingBasic Configuration, VLAN Configuration and Port Filtering Profile
    • LLDPLLDP Parameters and LLDP Interface Configuration
    • UsersUsers Configuration
    • Privilege LevelsPrivilege Level Configuration
    • SSHSSH Configuration
    • HTTPSHTTPS Configuration
    • Port Security LimitSystem and Port Configuration
    • Access ManagementAccess Management Configuration
    • 802.1XNetwork Access Server Configuration
    • ACLPorts, Rate Limiters and Access Control List
    • ARP InspectionPort Configuration, VLAN Configuration, Static Table and Dynamic TableAAA RADIUS and TACACS+
    • Port ClassificationQoS Ingress Port Classification
    • Port PolicingQoS Ingress Port Policers
    • Queue PolicingQoS Ingress Queue Policers
    • Port SchedulerQoS Egress Port Schedulers
    • Port ShapingQoS Egress Port Shapers
    • Port Tag RemarkingQoS Egress Port Tag Remarking
    • Port DSCPQoS Port DSCP Configuration
    • DSCP-Based QoSDSCP-Based QoS Ingress Classification
    • DSCP TranslationDSCP Translation
    • DSCP ClassificationDSCP Classification
    • QoS Control ListQoS Control List Configuration
    • Storm PolicingGlobal Storm Policer Configuration
    • PingICMP Ping
    • Cable DiagnosticsCable Status
    • CPU LoadCPU Load Information
    • Restart DeviceRestart the Device
    • Factory DefaultsFactory Defaults
    • Firmware UpgradeSoftware Upload
    • Firmware SelectSoftware Image Selection
    • ConfigurationDownload, Upload, Activate and Delete
