  •   5-port router Cudy WR6500H

    5-port router Cudy WR6500H

    Inquire about this item
    Price 145.59 €
    Want another price? Suggest yours!
    In stock.
    In stock: 20 pcs
    Manufacturer
    Cudy

    • General
    • Model VersionWR6500H 1.0
    • CPU ChipsetBCM6766
    • CPU Details2.0 GHz Quad-core, ARM Cortex-A7
    • Flash/ROM128 MB (1 Gbit) NAND
    • DDR/RAM512 MB (4 Gbit) DDR4
    • 5 GHz Wi-Fi Speed5765 Mbps
    • 2.4 GHz Wi-Fi Speed688 Mbps
    • 5 GHz Wi-Fi Streams4T4R (4×4 MIMO)
    • 2.4 GHz Wi-Fi Streams2T2R (2×2 MIMO)
    • Wi-Fi Antennas6× Fixed
    • 5 GHz Antenna Gain Max5.27 dBi
    • 2.4 GHz Antenna Gain Max5.19 dBi
    • FEM or PA/LNA5 GHz: 4× External, 2.4 GHz: 2× Internal
    • BeamformingTrue
    • Range PerformanceMax: 240 m (787 ft) (Indoor WiFi range varies depending on layout and wall materials)
    • Wall PerformanceTwo wooden walls <10 cm (4''), One concrete wall <20 cm (7'') or two concrete walls <10 cm (4'')
    • 2.5G RJ45 Ports1
    • Gigabit RJ45 Ports4
    • Ethernet Notes2.5G port is WAN; Gigabit ports are LAN
    • LED IndicatorsSystem, Internet, Wi-Fi, WPS
    • Physical ButtonsPower On/Off Button, WPS Button, Reset Button
    • Power InputDC Jack
    • Power MethodsDC
    • DC Power12V 1.5A
    • Power AdapterInput: 100 ~ 240 V, 50/60 Hz AC, Output: 12V 1.5A DC
    • Max Power Consumption17W
    • Operating Temperature0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉)
    • Storage Temperature-40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
    • Operating Humidity10% ~ 90% non-condensing
    • Storage Humidity5% ~ 95% non-condensing
    • CertificationsFCC, CE
    • Installation OptionsDesktop, Wall-mount
    • Dimensions253×152.5×48.2 mm (9.96×6×1.9 inches)
    • Product Weight580.4 g (20.47 oz.)
    • Package ContentsWR6500H, Power Adapter, Ethernet Cable, Installation Guide
