Interfaces

Gigabit Ethernet

Jumbo Frame Support

10240 bytes

Device Type

Switch - 8 ports - smart

Enclosure Type

Desktop, wall-mountable

Subtype

Gigabit Ethernet

Ports

8 x 10/100/1000 (PoE+)

Power Over Ethernet (PoE)

PoE+

PoE Budget

70 W

Performance

Switching capacity : 16 Gbps ¦ Forwarding performance : 11.9 Mpps

MAC Address Table Size

8K entries

Routing Protocol

IGMPv2, IGMP, IGMPv3

Remote Management Protocol

SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3

Encryption Algorithm

SSL

Authentication Method

RADIUS, TACACS+

Features

Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, Weighted Round Robin (WRR) queuing, store and forward, IPv6 support, Quality of Service (QoS), fanless, LACP support, LLDP support, Port Security, Energy Efficient Ethernet, Management Information Base (MIB), Strict Priority Queuing (SPQ), Class of Service (CoS), tagged VLAN, per port bandwidth control, 525KB packet buffer

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az

Status Indicators

Power, system, link/activity

Interfaces

8 x 1000Base-T - RJ-45 - PoE+ - 30 W

Power Device

Internal power supply

Voltage Required

AC 120/230 V ( 50/60 Hz )

Power Consumption Operational

90 Watt

MTBF

533,086 hour(s)

Compliant Standards

FCC Class A certified, RoHS, EN 60950-1, BSMI CNS 13438, C-Tick Class A, BSMI CNS 14336

Localisation

United Kingdom

Width

25 cm

Depth

10.4 cm

Height

2.7 cm

Weight

660 g

Service & Support

Limited lifetime warranty

Service & Support Details

Limited warranty - lifetime

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C

Humidity Range Operating

10 - 95% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C
