Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x

Interface

16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/AutoMDI/MDIX)

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity

Fanless

Power Supply

100-240VAC, 50/60Hz

Power Consumption

Maximum: 13.3W (220V/50Hz)

Dimensions ( W x D x H )

11.6*7.1*1.7 in. (294*180*44 mm)

Switching Capacity

32Gbps

Packet Forwarding Rate

23.8Mpps

MAC Address Table

8K

Jumbo Frame

10KB

Green Technology

Innovative energy-efficient technology saves power up to15%

Transfer Method

Store-and-Forward

Certification

FCC, CE, RoHs

Package Contents

16-Port Gigabit Desktop/Rackmount Switch
Power Cord
Installation Guide
Rackmount Kits
Rubber Feet

System Requirements

Microsoft® Windows® XP, Vista™, Windows 7 or Windows 8,MAC® OS, NetWare®, UNIX® or Linux.

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~70℃ (-40℉~158℉);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
